MERIDA SCULTURA 300 ENDURANCE

If you are looking for an affordable road bike with a super comfortable geometry and ample tyre clearance so that you could even run 35 mm wide tyres (including fenders), then look no further. The SCULTURA ENDURANCE 300 combines a beautifully made 6066 aluminium frame, featuring the same comfort orientated geometry as its carbon relatives and a full carbon fork for added vibration absorption with a reliable Tiagra 10-speed groupset.

The SCULTURA ENDURANCE is the perfect choice for more leisure-focused cyclists who want to enjoy long hours in the saddle while being comfortable and relaxed on the bike. Wide tyres offer plenty of comfort, even on the most pothole-littered country lanes, while a longer head tube provides a more relaxed riding position. An instant hit with the international cycling press and besides being given a 'comfort' award by RennRad, it also managed to get a long list of compliments like 'excellent comfort', ‘confidence inspiring', 'lively feel' and 'enjoyable' by reference cycling media such as Gran Fondo, Cyclingnews, Cyclingtips and Road.cc. Compared to its namesake, the SCULTURA, the ENDURANCE has a more comfort-orientated geometry, plenty of tyre clearance and seamless integration of the latest standards. It sits between the road-biased SCULTURA on one side and the gravel/adventure SILEX on the other, while the SCULTURA ENDURANCE GR lineup offers gravel-racing focussed options with off-road ready tyres and flared handlebars.

• Lightweight 6066 triple butted and hydroformed aluminium frame with comfort orientated geometry for confidence inspiring handling
• Shimano Tiagra 10-speed groupset
• MERIDA EXPERT SL II wheelset
• Full carbon tapered fork
• WIRE PORT cable integration

frame SCULTURA ENDURANCE LITE

frame size 4XS, 3XS, XXS, XS, S, M, L, XL

color SILK FOG GREEN (GREEN-SILVER)

fork SCULTURA ENDURANCE CF3 DISC

brakes Shimano Tiagra

rotors Shimano RT10

brake lever Shimano Tiagra

headset Acros ICR MERIDA EXTERNAL neck w/diecast splitring

handlebar MERIDA EXPERT SLII

handlebar stem MERIDA TEAM CC III

grip MERIDA ROAD Expert

derailleur (f) Shimano Tiagra

derailleur (r) Shimano Tiagra

shifters Shimano Tiaga disc

seat post MERIDA COMP CC

seat clamp MERIDA EXPERT

saddle MERIDA COMP SL

chain KMC X10

crank Shimano Tiagra

freewheel Shimano HG500

bottom bracket Shimano SM-BB72-41B

hubs Joytech D981-12 / Joytech D982TSE-R

rim MERIDA EXPERT SLII

tyre front Maxxis Detonator

tyre rear Maxxis Detonator

axles MERIDA COMP TR

spokes Black stainless

approx. weight 9.8 kg

Geometries

Frame Size	4XS	3XS	XXS	XS	S	M	L	XL
Tyre Sizes	28"	28"	28"	28"	28"	28"	28"	28"
ST seat tube [mm]	380	410	440	470	490	510	530	560
TT top tube [mm]	507	507	515	524	538	553	568	583
CS chain stay length [mm]	418	418	418	418	418	418	418	418
HTA head tube angle [°]	70	70	70.5	71	72	73	73	73.5
STA seat tube angle [°]	74.5	74.5	74	74	74	73.5	73.5	73.5
BD bottom bracket drop [mm]	70	70	66	66	66	66	66	66
HT head tube [mm]	125	130	140	152	161	177	197	222
FL fork length [mm]	380	380	380	380	380	380	380	380
R reach [mm]	360	360	360	366	376	380	389	397
S stack [mm]	528	532	539	552	565	584	603	629
WB wheel base [mm]	990	991	992	997	1001	1001	1017	1026
SH stand over height [mm]	656	680	708	734	752	770	790	818

Spare Parts

Download PDF

No.	Item-No.	Name	Info	Pieces	Torque NM
1	A2216000022	HEAD SET	MERIDA/VP8158(w/o crown race) (MH-P16/MH-P16)	1
2	A2161000211	CABLE GUIDE	for head tube	1
3	A2164000038	DISC COOLER	front; for FM160/FM180	1
4	A2298000265	SCREW	M5x0.8 L16mm	2
5	A2002000120	THRU AXLE	EXPERT TR; L=120mm M12x1.5 TL=12mm	1
6	A2298000059	SCREW	M5x0.8 L15mm	4
7	A2029000031	TUBE	foam; ID6mm; L400mm	2
8	A2029000036	TUBE	foam; ID5mm; L500mm	1
9	A2240000010	CABLE GUIDE	for FD	1
10	A2298000057	SCREW	M4x0.7 L8mm	1	3-4
11	A2258000056	CABLE PLUG	for rear brake	1
12	A2311000104	RD-HANGER	DH-068 for ROAD-RD	1
13	A2311000103	RD-HANGER	DH-067 for SHIMANO direct mount	1
14	A2300000129	SCREW	M3x0.5 L10mm	1	2-3
15	A2298000363	SCREW	M4x0.7 L5mm	1	3-4
16	A2002000119	THRU AXLE	EXPERT TR; L=162.5mm M12x1,5 TL=12mm	1
17	A2298000319	SCREW	M4x0.7 L9mm	1	3-4
18	A2054000107	EXPANDER	for fork steerer ID 23,6mm	1
19	A2029000057	TUBE	woven; L70mm for size 4XS/3XS/XXS	1
19	A2029000058	TUBE	woven; L90mm for size XS/S	1
19	A2029000059	TUBE	woven; L105mm for size M	1
19	A2029000060	TUBE	woven; L125mm for size L	1
19	A2029000061	TUBE	woven; L150mm for size XL	1
20	A2298000361	SCREW	M4x0.7 L12mm	2
21	A2164000089	MOUNT	for mounting a standard fender	2
